This document describes how to troubleshoot the common faults of 64Ah Energy Storage Battery (hereinafter simply put as battery). Before operating battery, please ensure that you are familiar with product features, functions, and safety precautions.
This document describes how to troubleshoot the common faults of 64Ah Energy Storage Battery (hereinafter simply put as battery). Before operating battery, please ensure that you are familiar with product features, functions, and safety precautions.
Symbol | Description |
| Indicates a potentially hazardous situation, if not avoided, could result in serious injury or death. |
| Indicates a potentially hazardous situation, if not avoided, may result in minor or moderate injury |
1. Important Safety Information
1.1 Warning Signs
| Risk of electric shock. |
| Do not expose battery to flame. |
| Battery is heavy enough to cause severe injury. |
| Keep battery away from children. |
| Corrosive electrolyte may leak from battery. |
| Operate as specified by the manual. |
| Explosive atmosphere. |
| Read the manual before operating. |
| Do not reverse polarities. |
|
|
1.2 Precaution
Risks of electrolyte leakage
- Do not subject battery to strong impact.
- Do not crush or puncture battery.
- Prevent battery from falling. In case of fall, turn off the battery immediately and stop using it.
- Do not open or mutilate batteries. Released electrolyte is harmful to the skin and eyes.
Risks of fire
- Do not expose battery to direct sunlight.
- Avoid contact with conductive objects such as wires.
- Keep battery away from fire source, inflammable, explosive and chemical materials.
- Do not dispose of batteries in a fire. The batteries may explode.
Risks of electric shock
- Do not touch battery with wet hands.
- Keep battery away from children and animals.
- A battery can present a risk of electric shock and burns by high short-circuited current.
- Battery installation and wire connection must be operated by professionals.
Risks of damage
- Keep a distance from water source.
- Do not subject battery to high voltage.
- Place battery on a flat surface. Do not place any foreign object on top of battery nor step on battery.
- Battery-connected power system should have reinforced insulation
Table 1-1 Responses to Emergencies
Event | Description and recommended actions |
Leakage | Inhalation: leave the contaminated area right now.
|
Fire | Battery may catch fire when heated above 150℃. Please implement the following actions:
|
Wet battery | If battery becomes wet or has been submerged in water, do not access it. Immediately contact your distributor for technical assistance. |
Damage | Damaged battery is dangerous and must be handled with utmost care. They cannot be used anymore and could pose a safety threat to people or property. If battery is suspected to be damaged, stop any operation and return it to distributor. |
2. Preparation for Visit
- Check if a component is faulty or if the firmware is to be updated. Refer to chapter 4 and chapter 5 and determine the fault location based on fault information reported by the user.
- Prepare a USB key for firmware upgrade or log exporting.
- Obtain the SOC information of user’s system and prepare a module with similar SOC or BMS Box for onsite replacement.
- Prepare a set of network cables and power wires.
- Prepare uninstallation and installation tools, such as hex key and wrench.
3. Onsite Process
Follow the steps below to locate the fault and take photos for every step:
- (Optional) if only the firmware needs to be updated, implement the upgrade through the USB port of the BMS Box. For how to upgrade firmware through the USB port, refer to Firmware Upgrade Via USB.
- Export log through the USB port. For how to export logs, refer to Log Exporting.
- Check PCS. (if the PCS reports any fault and if it works properly)
- Check the ESS system. ( if any damage on appearance)
- Check cables and wires. (Whether they are inserted properly or not and whether they are damaged or not)
- Reset the breaker to check if the fault still exists.
- Check the LED status and take actions referring to the LED display in chapter 4.
- Confirm the error code displayed on the screen of the PCS is consist with that the user reports. Refer to the error code in chapter 5.
- Confirm the faulty component.
- Replace the faulty one. For how to replace a BMS Box or Module, refer to the Battery Replacement Guide.
